一、Product Overview
The building lighting control part consists of building lighting control equipment and is equipped with lighting control switches, including traditional switches, remote control switches, and intelligent dimming devices. The lighting demonstration cabinet is a semi physical demonstration object for the lighting control part of buildings. Adopting a layered structure that can simulate the entire lighting effect of the floor, using a semi physical model and divided into five layers, reflecting various lighting scenarios. Using a DDC controller, on-site data collection and switch control can be achieved, and lighting circuit on-off control can be completed. Communication with the upper computer system can be achieved through LonWorks bus devices.
二、Technical Parameter
1)Working power supply: three-phase four wire 380V ± 10% 50Hz；
2)Safety protection: leakage protection (operating current ≤ 30mA) overcurrent protection, fuse protection；
3)Boundary dimension: 1500 ×750× 1560mm；
4)Rated power:<0.5KW；
5)Environmental temperature: -10 ℃~40 ℃；
6)Relative humidity:<85%；
7)Equipment weight: 125Kg。
三、Practical training projects
1.By controlling the luminous time and brightness of the lighting source, various lighting scenes can be remotely controlled;
2.Realize intelligent management and simplified operation to meet the requirements of future lighting layout and control mode changes;
3.Intelligent design focuses on public lighting that consumes a lot of electricity. Group switches can be used to control the lighting of the entire area, and automatic brightness control and timing switches can be used to achieve intelligent lighting;
4.According to the floor situation, scientifically arrange the timing and lighting conditions, use lighting equipment reasonably, and effectively save energy;
5.The lighting fixtures have light tubes, energy-saving lamps, spotlights, etc., while ensuring the safety and reliability of the lighting fixtures;
6.Lighting control supports multiple methods: timing scheduling control, scene control, and remote forced control;
7.Lighting current monitoring.
